New Addition. Article coming soon.

What equipment do you use? Post pictures and descriptions of your microscope(s) here!
Post Reply
Message
Author
einman
Posts: 1267
Joined: Tue Feb 24, 2015 1:03 am

New Addition. Article coming soon.

#1 Post by einman » Mon Sep 12, 2016 10:44 pm

So I finally acquired an Olympus SZh to compare against its competitors in the same time period from Nikon, AO, B&L and Zeiss. I will be submitting an article soon to the magazine discussing the scopes and my opinions on their performance, utility, costs etc.

Below are some pics of the new arrival. I would have preferred an Olympus SZH10 but given the cost I could not pass up on this one.









JimT
Posts: 3247
Joined: Fri Oct 24, 2014 1:57 pm

Re: New Addition. Article coming soon.

#2 Post by JimT » Mon Sep 12, 2016 10:57 pm

Looking forward to your article and comparison photos. BTW, based on the poster on the wall in your first photo you must live in an interesting place.

einman
Posts: 1267
Joined: Tue Feb 24, 2015 1:03 am

Re: New Addition. Article coming soon.

#3 Post by einman » Mon Sep 12, 2016 11:04 pm

JimT wrote:Looking forward to your article and comparison photos. BTW, based on the poster on the wall in your first photo you must live in an interesting place.
My interests are quite varied. I had several live snakes in my lab until recently. However given my time is limited I am focusing on insects. Probably should take down the poster to make room for one on Arachnids I have. More appropriate to my studies.

User avatar
KurtM
Posts: 1542
Joined: Tue Jun 09, 2015 12:08 am
Location: League City, Texas
Contact:

Re: New Addition. Article coming soon.

#4 Post by KurtM » Mon Sep 12, 2016 11:25 pm

How I wish I could take it for a test drive, wow!

Like the illuminators too. Do the pingpong ball diffusers work pretty well?
Cheers,
Kurt Maurer
League City, Texas
email: ngc704(at)aol(dot)com
http://sawdustfactory.nfshost.com/microscopes/
https://www.flickr.com/photos/67904872@ ... 912223623/

Tom Jones
Posts: 129
Joined: Wed Apr 13, 2016 3:47 pm

Re: New Addition. Article coming soon.

#5 Post by Tom Jones » Tue Sep 13, 2016 1:31 am

I have an SZH too. You're going to love it! :D

Tom

einman
Posts: 1267
Joined: Tue Feb 24, 2015 1:03 am

Re: New Addition. Article coming soon.

#6 Post by einman » Tue Sep 13, 2016 1:32 am

I also have a Nikon SMZ-U which was my favorite scope. I have wanted to compare these 2 for quite some time.

einman
Posts: 1267
Joined: Tue Feb 24, 2015 1:03 am

Re: New Addition. Article coming soon.

#7 Post by einman » Tue Sep 13, 2016 1:50 am

KurtM wrote:How I wish I could take it for a test drive, wow!

Like the illuminators too. Do the pingpong ball diffusers work pretty well?
Kurt,
You may recall some earlier posts in which I described usig the ping pong ball diffusers quite some time ago. They work well but do cut down on the light considerably. Those, as you probably know, are IKEA LED lights. Would be great if they had a little more wattage.

Alternatively I have used some Older Bausch Lomb fiberoptic illuminators with filters placed inside the casing. Worked great.

einman
Posts: 1267
Joined: Tue Feb 24, 2015 1:03 am

Re: New Addition. Article coming soon.

#8 Post by einman » Mon Sep 19, 2016 9:16 pm

Ok here is my first camera shot of a Wood Cockroach. Interestingly enough the adapter I used to mount my T3I is the same used for my AO microscopes. It was made by RAfcamera. Unfortunately it is not parfocal. This is using the SZH-PT35 camera tube on the left of the microscope. The one to the back of the microscope require a 150mm tube apparently which I have yet to locate for any reasonable price. Although I did spend some money trying alternative approaches which did not pan out.

This is using the 1X objective at 7.5X on the zoom. Lighting is not very good as I was just testing the set-up and had only one illuminator on the specimen. But I was excited to have just found the AO adapter that worked. Camera set to "no flash". No fiddling with settings yet.


Better Lighting also not in petri dish. Reflections make a big difference.

These pics were just a quick screen of the camera/scope. I will do more in depth with the article. You may notice the second pic has a bluish tint as the light incorporates a blue filter. I actually prefer the more "yellow" light most of the time for reflected light. It varies with the subject.

User avatar
billben74
Posts: 1020
Joined: Sat Dec 26, 2015 10:33 pm
Location: Cambridge, UK

Re: New Addition. Article coming soon.

#9 Post by billben74 » Wed Sep 28, 2016 6:15 pm

Nice pics. Look forward to the article.
