Re: Pollen. There's lots of it about.

#91 Post by Roldorf » Sat Sep 14, 2019 1:56 pm

Sweet Basil growing wild in the garden must have seeded itself from last year (we never planted it).

Pollen is an unusual shape:-

Edit included stem cross section

Last edited by Roldorf on Mon Apr 13, 2020 8:45 am, edited 3 times in total.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

User avatar
mrsonchus
Posts: 3702
Joined: Tue Feb 03, 2015 9:42 pm
Location: Cumbria, UK

Re: Pollen. There's lots of it about.

#92 Post by mrsonchus » Sat Sep 14, 2019 2:07 pm

A nice image too. That is an unusual surface, it seems to have depressions with little 'peaks'.
I''ll look it up and see what they are if possible.

Another nice interesting post my friend. :)
John B

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#93 Post by Roldorf » Sat Sep 14, 2019 3:21 pm

Hi John,
That's what I thought and the reason I decided to post it. I checked it out on PalDat and it looks exactly the same. The image under the scope was much clearer unfortunately the stack didn't turn out as good, I think I rushed it a bit. (was so excited Ha :D )

Reminded me of a pineapple.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

User avatar
mrsonchus
Posts: 3702
Joined: Tue Feb 03, 2015 9:42 pm
Location: Cumbria, UK

Re: Pollen. There's lots of it about.

#94 Post by mrsonchus » Sat Sep 14, 2019 3:35 pm

Have you snuk-in that nice stem section.... :D

Yes I also had a peek, it's a distinctive grain once seen.

Good post as always Roldorf.
John B

david_b
Posts: 103
Joined: Wed Aug 28, 2019 1:07 pm

Re: Pollen. There's lots of it about.

#95 Post by david_b » Sat Sep 14, 2019 4:24 pm

Roldorf wrote:
Fri Jul 19, 2019 2:02 pm
Yes if I could donate (to Micam) with anything other than PayPal, I would have done it, a very nice piece of software.

Pollen from Nasturtium but not Nasturtium:
Possibly common ragwort?

http://www.northumbrianbees.co.uk/polle ... -jacobaea/

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#96 Post by Roldorf » Sat Sep 14, 2019 6:01 pm

Hi David_b

Thanks for the suggestion of ragweed. It was (and is) the correct flowering time for them, however from what I could find on the internet the Ragweed pollen is only 15-25 um in diameter which would rule out this enormous grain. If I am wrong on the size please let me know.
I have to admit it does look like them.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#97 Post by Roldorf » Tue Sep 17, 2019 6:32 pm

Out in the forest on Sunday and found this. It's amazing how many plants were used for medical purposes in the past.


Last edited by Roldorf on Mon Apr 13, 2020 8:46 am, edited 1 time in total.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#98 Post by Roldorf » Mon Oct 14, 2019 3:46 pm

Almost run out of flowers but found this one in the forest while looking for mushrooms and interesting stones.

Last edited by Roldorf on Mon Apr 13, 2020 8:48 am, edited 1 time in total.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

User avatar
mrsonchus
Posts: 3702
Joined: Tue Feb 03, 2015 9:42 pm
Location: Cumbria, UK

Re: Pollen. There's lots of it about.

#99 Post by mrsonchus » Mon Oct 14, 2019 4:01 pm

What a beautiful little plant! I like the hidden pollen-grains too.
Nicely-done.
John B

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#100 Post by Roldorf » Wed Oct 16, 2019 2:54 pm

More from our garden. This plant is on the black list for invasive species in Germany, maybe I should pull it out, only its so pretty (I think I probably have the wrong identification ;) )

Last edited by Roldorf on Mon Apr 13, 2020 9:25 am, edited 2 times in total.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#101 Post by Roldorf » Sun Apr 12, 2020 8:00 pm

First one of the year, from the garden of course. It took me four hours to remember how I combined the images and still haven't remembered the whole thing try again tomorrow with a different plant :-

Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#102 Post by Roldorf » Mon Jun 01, 2020 12:56 pm

A favorite among children at this time of year (me included). This growing in the cobbles in our garden is however the biggest I have ever seen at 153 cm.



Sorry no crossections as I didn't want to maul such a magnificent specimen. :(

As usual you can see the image in all it's glory by clicking on it. :D
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

User avatar
mrsonchus
Posts: 3702
Joined: Tue Feb 03, 2015 9:42 pm
Location: Cumbria, UK

Re: Pollen. There's lots of it about.

#103 Post by mrsonchus » Mon Jun 01, 2020 10:25 pm

Very nice - a superb image of the foxglove.
I like the presentation very much, with the example pollen-grain included.
Nicely-done!
John B

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#104 Post by Roldorf » Tue Jun 02, 2020 2:21 pm

Another from our garden.

Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#105 Post by Roldorf » Tue Jun 02, 2020 2:28 pm

As I was stacking the pollen images I came across a peculiar thing with Photoshop.

It would seem that PS increases the size of the image by 50%. I had wanted to put some comparison image stacks from Picolay, Photoshop and CombineZP. When I came to measure the pollen grains with Micam after stacking I noticed that the size on CombineZP and the Picolay images were the same, however the stacked image from Photoshop showed a 50% increase compared to the others, 21 micros as opposed to 32 in photoshop.

So:- I am now going to grab some images of my grad scale stack and compare.

Anyone else noticed this?
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#106 Post by Roldorf » Tue Jun 02, 2020 3:08 pm

Ok it's done here are the results:- All use the same 4 images from the microscope.


CombineZP



Picolay



Photoshop

It would seem that Photoshop showing a distance of 76 um which should be 50 um is as I suspected scaling the image by 50% when stacking or saving.

CombineZP and Picolay both show the correct size and do not scale the image.


So 'Be warned' if you need to measure after stacking be careful which software you use.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Mraster2
Posts: 35
Joined: Sat May 02, 2020 7:29 pm

Re: Pollen. There's lots of it about.

#107 Post by Mraster2 » Tue Jun 02, 2020 7:27 pm

I dont know Micam or Photoshop but is it significant that Ps is rotated 90deg cf the other two ?
How does micam do its pixel counting, is there an aspect ratio problem maybe.

Just throwing out wild guesses !

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#108 Post by Roldorf » Tue Jun 02, 2020 9:33 pm

I had the same questions, which is why I used the microscope calibration slide.

I didn't rotate any of the images, they are as they came from the camera and as the program's display them, but you are correct the original images are in portrait mode (and show as that on the windows properties details 3456x5184 pixels), even though the camera was in landscape mode when the images were taken.
Micam is a software program for Microscope Image Capture and Measurement hence the name MICAM. The main function is to measure, enhance and document images (I stack them first in other software (Photoshop, CombineZP, Picolay) then import them into Micam for documentation purposes, this is where I measure the pollen grains and where I found the discrepancy in Photoshop. It makes no difference which way round the images are, it still shows the 50% increase in size.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#109 Post by Roldorf » Tue Jun 02, 2020 9:42 pm

My next step is to use a single image in photoshop make a small edit then save it to see if it distorts it, a task for tomorrow.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Mraster2
Posts: 35
Joined: Sat May 02, 2020 7:29 pm

Re: Pollen. There's lots of it about.

#110 Post by Mraster2 » Tue Jun 02, 2020 10:16 pm

yes, sorry, I was a bit brief in my reply, what I meant was that although I knew of those two progs. I didnt know them intimately through use, nor how they went about things, their assumptions etc.

I have only just started measuring things in my imaging (having only just discovered a stage graticule in the box of bits that I inherited !)
Simply experimenting with an image of the scale (taken with the same settings etc !!) overlaid in a partially transparent layer in Gimp on top of my pollen images. Then constructing by hand a line or other marker if I want to keep a record of it on the image.

I am interested in your findings, I do have Micam downloaded (just rountuit problems ;) ), so thanks, I will be paying it close attention in my Picolay etc.

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#111 Post by Roldorf » Wed Jun 03, 2020 5:17 am

No Stack just a single image with text added edited in Photoshop CS4. Should read 50um still the 50% increase.

Now back to images of pollen.



Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

MichaelG.
Posts: 2054
Joined: Mon Apr 10, 2017 8:24 am
Location: NorthWest England

Re: Pollen. There's lots of it about.

#112 Post by MichaelG. » Wed Jun 03, 2020 10:07 am

Just came across this excellent paper from the ‘Journal of Pollen Ecology”

https://www.pollinationecology.org/inde ... h%5B%5D=57

... duly downloaded for more careful study.

MichaelG.
Too many 'projects'

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#113 Post by Roldorf » Wed Jun 03, 2020 11:08 am

Hi thanks for that.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

User avatar
75RR
Posts: 6951
Joined: Sun Oct 12, 2014 2:34 am
Location: Estepona, Spain

Re: Pollen. There's lots of it about.

#114 Post by 75RR » Wed Jun 03, 2020 12:39 pm

Roldorf wrote:
Tue Jun 02, 2020 9:33 pm
I had the same questions, which is why I used the microscope calibration slide.

I didn't rotate any of the images, they are as they came from the camera and as the program's display them, but you are correct the original images are in portrait mode (and show as that on the windows properties details 3456x5184 pixels), even though the camera was in landscape mode when the images were taken.
Micam is a software program for Microscope Image Capture and Measurement hence the name MICAM. The main function is to measure, enhance and document images (I stack them first in other software (Photoshop, CombineZP, Picolay) then import them into Micam for documentation purposes, this is where I measure the pollen grains and where I found the discrepancy in Photoshop. It makes no difference which way round the images are, it still shows the 50% increase in size.
I wonder if the problem might be that you are reducing the width (3456) to 1202 and the height (5184) to 800 rather than the other way around.

i.e. try reducing the side that is 5184 to 1202 and the one that is 3456 to 800.
Zeiss Standard WL (somewhat fashion challenged) & Wild M8
Olympus E-P2 (Micro Four Thirds Camera)

User avatar
mrsonchus
Posts: 3702
Joined: Tue Feb 03, 2015 9:42 pm
Location: Cumbria, UK

Re: Pollen. There's lots of it about.

#115 Post by mrsonchus » Wed Jun 03, 2020 1:05 pm

When calibrating the measurement system with MICAM and indeed with ToupView, which is also able to measure images not captured with the program, the pixels per inch value is the factor that sets the measurement calibrations per defined objective....
So, if the PPI value is different from when measurement is defined for a particular objective, the measurement will be wrong.

I don't know if this helps, but this is what I've experienced, and setting the PPI did correct the problem when I measured an imported image with ToupView.
John B

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#116 Post by Roldorf » Wed Jun 03, 2020 3:40 pm

More tests. :geek:

Hi 75rr and John the image that I used comes direct from the camera and is 3456 x 5184 at 72x72 dpi and was the same for Picolay and CombineZP. It opens in Photoshop at the correct size and resolution. Saving the image saves it at it's original size. All of the images are in portrait mode.
When opening the images in CombineZP and Picolay they are automatically rotated counterclockwise into landscape mode, I have no idea why. After stacking they show the correct sizes in Micam 2.4.
If I rotate the image CCW in Photoshop and save it, when opening the image in Micam and measuring it shows the correct dimension. :?: :?: :?: :?: :?:
I have just opened the previously dimensioned Photoshop edit no stack, rotated 90CCW, saved, opened in Micam put in a new dimension and GUESS WHAT:-



However I still don't understand what is happening. :evil: :evil: :evil:
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#117 Post by Roldorf » Wed Jun 03, 2020 3:47 pm

Photoshop must put some kind of marker in the file that causes Micam to open it as displayed in Photshop, whereas an image opened in Micam from Combine ZP Picolay or direct from the camera gets rotated 90 CCW. Rotating the previous image by 90 brings back the 75. Rotating it 180 brings it back to 50 clockwise or counterclockwise.
So in conclusion it must be the 2:3 ratio in the camera that causes the problem with Photoshop and Micam.

Glad I sorted that out. :lol: :lol: :lol: :lol: :lol:
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#118 Post by Roldorf » Tue Jun 09, 2020 6:11 pm

One from the garden amazing how many plants are used for medicinal purposes.

Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

MichaelG.
Posts: 2054
Joined: Mon Apr 10, 2017 8:24 am
Location: NorthWest England

Re: Pollen. There's lots of it about.

#119 Post by MichaelG. » Sun Jun 14, 2020 5:31 am

Here’s a fascinating little story for Hay Fever sufferers:
https://www.wired.co.uk/article/hay-fev ... =applenews

MichaelG.
Too many 'projects'

Roldorf
Posts: 480
Joined: Tue Apr 23, 2019 6:58 pm
Location: Northern Germany

Re: Pollen. There's lots of it about.

#120 Post by Roldorf » Sun Jun 14, 2020 1:21 pm

An update on the foxglove growing in our back garden. When I did the first post it was 153 cm tall. It is now 184cm and still has half the flower stack to blume.
Location: Northern Germany

Unknown Brand: Optika SFX 91: Bresser Science Infinity: Canon 4000d

Post Reply
